| SPECIFICATIONS |
| Brand |
Thermaltake |
| Series |
UX200 SE |
| Model |
CL-P116-AL12SW-A |
| Colour |
White |
| Compatibility |
Intel LGA 1700, 1200, 1156, 1155, 1151, 1150 |
| AMD AM5, AM4, FM2, FM1, AM3+, AM3, AM2+, AM2 |
| TDP |
170W |
| Overall Dimension |
122mm x 61mm x 156.2mm |
| Heatsink Material |
Aluminium Fins |
| Copper Heatpipes |
| Fan Dimension |
120mm x 120mm x 25mm |
| Fan Quantity |
1pcs |
| Fan Speed |
800~1800 RPM (PWM) |
| Max. Air Flow |
62.72 CFM |
| Max. Static Pressure |
1.47 mmH2O |
| Noise |
25.0 dBA |
| Rated Voltage |
12V |
| Started Voltage |
6.0 V |
| Rated Current |
0.3 A |
| Power Input |
4.32W |
| Bearing Type |
Hydraulic Bearing |
| Connector |
5V RGB header |
| 2510 - 4Pin |
| Fan Lifetime |
30,000 hours |
| Cooling Power |
170W |
| Additional Features |
15 high lumen addressable LEDs |
| Supports motherboard sync |
| High volume airflow design |
| Reliable hydraulic bearing |
| Warranty Information |
| Warranty |
2 Year Warranty |
