| SPECIFICATIONS |
| Brand |
CoolerMaster |
| Series |
MasterAir |
| Model |
MAP-T6PN-218PC-R1 |
| CPU Socket |
Intel LGA 2066 / 2011-v3 / 2011 / 1151 / 1150 / 1155 / 1156 / 1366 / 775 socket |
| AMD AM4 / AM3 / AM3 / AM2 / AM2 / FM2 / FM2 / FM1 socket |
| Fan Specifications |
| Fan Dimensions |
120 x 120 x 25 mm |
| Fan Speed |
600 – 1,800 RPM (PWM) ± 10% |
| Fan Air Flow |
53.38 CFM (Max) |
| Fan Air Pressure |
1.65mm H2O (Max) |
| Fan MTTF |
40,000 hours |
| Fan Noise Level |
35 dBA (Max) |
| Fan Connector |
4-Pin |
| Fan Rated Voltage |
12 VDC |
| Fan Rated Current |
0.30 A |
| Fan Safety Current |
0.37 A |
| Fan Power Consumption |
4.44 W |
| Heat Sink Specifications |
| Heat Sink Dimensions (LxWxH) |
116 x 60 x 158 mm |
| Heat Sink Material |
6 Heat Pipes / Direct Contact / Aluminum Fins |
| Heat Sink Weight |
616g |
| Heat Pipes Dimensions |
Ø6 mm |
| General |
| Features |
Wired RGB LED Controller - No Software needed |
| 6x Heatpipes with Continuous Direct Contact 2.0 Technology (CDC 2.0) Increases the Surface Area of the Copper Base by 45% |
| 2x MasterFan 120 Air Balance RGB accelerates removal of heat |
| Stacked Fin Array Ensures the Least Amount of Airflow Resistance Allowing Cooler Air into the Heatsink |
| Lighting |
RGB, 16.7 Million Colours |
| Compact Size RGB LED Controller (Included) |
| 6x Pre-Set RGB Modes |
| Compatible with: |
| Asus Aura Sync |
| Gigabyte RGB Fusion |
| MSI Mystic Light Sync |
| ASRock RGB LED |
| Dimensions |
130.9 x 112.8 x 166.5mm (W x D x H) |
| Warranty Information |
| Warranty |
2 Year Warranty |
