MSI Nvidia GeForce RTX 4080 Gaming X SLIM 16GB GDDR6X

The NVIDIA® GeForce RTX™ 4080 delivers the ultra-performance and features that enthusiast gamers and creators demand. Bring your games and creative projects to life with ray tracing and AI-powered graphics with DLSS 3. It’s powered by the ultra-efficient NVIDIA Ada Lovelace architecture and up to 16GB of superfast G6X memory. The MSI GAMING SLIM series is a thinner variant of the GAMING series while maintaining high-performance capabilities and aggressive looks.

Its lightened design is made for those building a gaming rig with space constraints. Elevate performance with TRI FROZR 3 cooling and its key features – TORX FAN 5.0, Core Pipe, and Airflow Control. Stay cool and quiet. MSI’s TRI FROZR 3 thermal design enhances heat dissipation all around the graphics card.

TORX FAN 5.0 is a culmination of fan design improvements to increase the air pressure and flow into the heatsink. Ring arcs link three sets of fan blades that tilt 22 degrees together to maintain high-pressure airflow even at slower rotational speeds. The resulting increased airflow is +23% compared to an axial fan.

The heat from the GPU and memory modules is immediately captured by a solid nickel-plated copper baseplate and then rapidly transferred to an array of heat pipes. This widening of the thermal transfer systems with highly efficient mechanisms improves overall efficiency.

Core pipes are precision-crafted to make maximum use of the available space. A squared section of heat pipes fully touches the GPU baseplate and spreads the heat along the full length of the heatsink. Airflow Control improves airflow dynamics through the Wave Curved 2.0 and updated deflectors design for optimizing the balance between cooling and quieter acoustics.

FEATURES:

• Boost Clock – 2595 MHz (GAMING & SILENT Mode)
• Memory Speed – 22.4Gbps
• 16GB GDDR6X
• Two DisplayPort ports and two HDMI Ports
• TRI FROZR 3 Thermal Design
• TORX Fan 5.0: Fan blades linked by ring arcs and a fan cowl work together to stabilize and maintain high-pressure airflow.
• Copper Baseplate: Heat from the GPU and memory modules is captured by a copper baseplate and then rapidly transferred to Core Pipes.
• Core Pipe: A section of square-shaped heat pipes make maximum contact over the GPU, then spread the heat to the heatsink.
• Airflow Control: Sections of different heatsink fins disrupt unwanted airflow harmonics and reduce noise.
• Dual BIOS gives you the choice to prioritize full performance in GAMING mode or low noise in SILENT mode.

SPECIFICATIONS:

• Graphics Processing Unit: NVIDIA® GeForce RTX™ 4080 16GB
• Interface: PCI Express® Gen 4
• Core Clocks: Extreme Performance: 2610 MHz (MSI Center), Boost: 2595 MHz (GAMING & SILENT Mode)
• CUDA® Cores: 9728 Units
• Memory Speed: 22.4Gbps
• Memory: 16GB GDDR6X
• Memory Bus: 256-bit
• Output: DisplayPort x 2 (v1.4a), HDMI™ x 2 (Supports 4K@120Hz HDR, 8K@60Hz HDR, and Variable Refresh Rate as specified in HDMI 2.1a)
• HDCP Support: Yes
• Power Consumption: 320W
• Power Connections: 16-pin x1
• Recommended PSU: 850W (Min.750W)
• DirectX Version Support: 12 Ultimate
• OpenGL Version Support: 4.6
• Maximum Displays: 4
• G-Sync® Technology: Yes
• Digital Maximum Resolution: 7680 x 4320
• Product Dimensions: 32.2 x 13.6 x 6.2 cm
• Product Weight: 1673g

WHAT’S IN THE BOX:

• MSI GeForce RTX 4080 Gaming X SLIM 16GB Graphics Card x1
