| SPECIFICATIONS |
| Brand |
Gigabyte |
| Series |
Modular Power Supply |
| Model |
P750GM |
| Wattage |
750 W |
| Certification |
80 PLUS Gold |
| Modular |
Fully-Modular |
| Efficiency |
90% at Typical Load |
| Connectors |
1x ATX/MB 20+4 Pin (610 mm) |
| 2x CPU/EPS 4+4 Pin (600 mm) |
| 4x PCI-e 6+2 Pin (600mm+150mm) |
| 8x SATA (600mm+150mm+150mm+150mm) |
| 1x 4-Pin Peripheral x 3 + 4-Pin Floppy (500mm+120mm+120mm+120mm) |
| PFC |
Active PFC (>0.9 Typical) |
| Performance |
| Maximum Output Capacity |
750 W |
| Input Current |
12-6 A |
| Input Voltage |
100 - 240 Vac (Full Range) |
| Input Frequency Range |
60 - 50 Hz |
| Hold Up Time |
>16ms |
| Power Good Signal |
100-500 msec |
| General |
| Colour |
Black |
| Cooling System |
120mm Hydraulic Bearing ( HYB ) Fan |
| MTBF |
>100,000 Hours |
| Protection |
OVP/OPP/SCP/UVP/OCP/OTP |
| Dimensions |
150 x 140 x 86 mm |
| Warranty Information |
| Warranty |
5 Year Warranty |
