Gigabyte GeForce RTX 4070 SUPER EAGLE OC ICE 12GB
Gigabyte GeForce RTX 4070 SUPER EAGLE OC ICE 12GB
The WINDFORCE cooling system features three 80mm unique blade fans, alternate spinning, 4 composite copper heat pipes directly touch the GPU, 3D active fans and Screen cooling, which together provide high efficiency heat dissipation. The 3D Active Fan provides semi-passive cooling, and the fans will remain off when the GPU is in a low load or low power game. The shape of the copper heat pipe maximizes the direct contact area with the GPU. The heat pipe also covers the VRAM through a large metal plate contact to ensure proper cooling. Extended heatsink allows air to pass through, providing better heat dissipation. With 16.7M customizable color options and numerous lighting effects, you can choose any lighting effect or synchronize with other devices in GIGABYTE CONTROL CENTER. The metal back plate not only provides an aesthetical shape, but also enhances the structure of the graphics card to provide complete protection. The factory default setting is OC mode, which provides users with the best performance. However, switching to silent mode will enjoy a quieter experience. When experiencing any power supply abnormality, the indicator will alert gamers by flashing light.
Graphics Processing | GeForce RTX 4070 SUPER |
Core Clock | 2535 MHz (Reference Card: 2475 MHz) |
CUDA Cores | 7168 |
Ray Tracing Cores | 56 |
Tensor Cores | 224 |
Streaming Multi-Processors | 56 |
Memory Clock | 21000 MHz |
Memory Size | 12 GB |
Memory Type | GDDR6X |
Memory Bus | 192 bit |
Memory Bandwidth (GB/sec) | 504 GB/s |
Card Bus | PCI-E 4.0 x16 |
Digital max resolution | 7680 x 4320 |
Multi-view | 4 |
Card size | 261mm x 126mm x 50mm |
PCB Form | ATX |
DirectX | 12 Ultimate |
OpenGL | 4.6 |
Recommended PSU | 700w |
Power Connectors | 1 x 16-pin |
Output | 3 x DisplayPort 1.4a 1 x HDMI 2.1a |
Multi-GPU Support | No |
Accessories | Quick guide One 16 pin to two 8-pin power adaptor |
