ASUS PRIME B760-PLUS D4 DDR4 Intel B760 Raptor Lake LGA 1700 ATX Desktop Motherboard
ASUS PRIME B760-PLUS D4 DDR4 Intel B760 Raptor Lake LGA 1700 ATX Desktop Motherboard
Regular price
R 3,799.00
Regular price
Sale price
R 3,799.00
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
| SPECIFICATIONS | |
| Brand | ASUS |
| Series | PRIME B760-PLUS D4 |
| Model | 90MB1CW0-M0EAY0 |
| CPU | Intel Socket LGA1700 for 13th Gen Intel Core & 12th Gen Intel Core, Pentium Gold and Celeron |
| Processors* | |
| Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0** | |
| * Refer to www.asus.com for CPU support list. | |
| ** Intel Turbo Boost Max Technology 3.0 support depends on the CPU types. | |
| Chipset | Intel B760 Chipset |
| Memory | 4 X DIMM, Max. 128GB, DDR4 5066(OC)/5000(OC)/4800(OC)/4600(OC)/4400(OC)/4266(OC)/4000(OC)/3733(OC)/3600(OC)/3466(OC)/3400(OC)/3333(OC)/3200/3000/2933/2800/2666/2400/2133 Non-ECC, Un-Buffered Memory* |
| Dual Channel Memory Architecture | |
| Supports Intel Extreme Memory Profile (XMP) | |
| OptiMem | |
| * Supported Memory Types, Data Rate (Speed), And Number Of DRAM Modules Vary Depending On The CPU And Memory Configuration, For More Information Please Refer To CPU/Memory Support List Under The Support Tab Of Product Information Site Or Visit Https://www.asus.com/support/. | |
| Graphics | 1 X DisplayPort** |
| 1 X VGA Port | |
| 1 X HDMI Port*** | |
| * Graphics Specifications May Vary Between CPU Types. Please Refer To www.intel.com For Any Updates. | |
| ** Supports Max. 4K@60Hz As Specified In DisplayPort 1.4. | |
| *** Supports 4K@60Hz As Specified In HDMI 2.1. | |
| Expansion Slots | Intel 13th & 12th Gen Processors* |
| 1x PCIe 5.0 X16 Slot | |
| Intel B760 Chipset | |
| 1x PCIe 4.0 X16 Slot (Supports X4 Mode) | |
| 2x PCIe 3.0 X1 Slots | |
| Note: To Ensure Compatibility Of The Device Installed, Please Refer To https://www.aasus.com/support/ For The List Of Supported Peripherals. | |
| Storage | Total Supports 3x M.2 Slots And 4x SATA 6Gb/S Ports* |
| Intel 13th & 12th Gen Processors | |
| M.2_1 Slot (Key M), Type 2242/2260/2280 (Supports PCIe 4.0 X4 Mode) | |
| Intel B760 Chipset | |
| M.2_2 Slot (Key M), Type 2242/2260/2280/22110 (Supports PCIe 4.0 X4 Mode) | |
| M.2_3 Slot (Key M), Type 2242/2260/2280 (Supports PCIe 4.0 X2 Mode) | |
| 4x SATA 6Gb/S Ports | |
| * Intel Rapid Storage Technology Supports SATA RAID 0/1/5/10. | |
| Ethernet | 1x Realtek 2.5Gb Ethernet |
| Wireless & Bluetooth | Vertical M.2 slot only (Key E, CNVi & PCIe)* |
| * Wi-Fi module is sold separately. | |
| USB | Rear USB (Total 6 Ports) |
| 1x USB 3.2 Gen 2x2 Port (1 X USB Type-C) | |
| 2x USB 3.2 Gen 2 Ports (2 X Type-A) | |
| 1x USB 3.2 Gen 1 Port (1 X Type-A) | |
| 2x USB 2.0 Ports (2 X Type-A) | |
| Front USB (Total 7 Ports) | |
| 1x USB 3.2 Gen 1 Connector (Supports USB Type-C) | |
| 1x USB 3.2 Gen 1 Header Supports 2 Additional USB 3.2 Gen 1 Ports | |
| 2x USB 2.0 Headers Support 4 Additional USB 2.0 Ports | |
| Audio | Realtek 7.1 Surround Sound High Definition Audio CODEC* |
| - Supports: Jack-Detection, Multi-Streaming, Front Panel Jack-Retasking | |
| - Supports Up To 24-Bit/192 KHz Playback | |
| Audio Features | - Audio Shielding |
| - Premium Audio Capacitors | |
| - Dedicated Audio PCB Layers | |
| * A Chassis With An HD Audio Module In The Front Panel Is Required To Support 7.1 Surround Sound Audio Output. | |
| Back Panel I/O Ports | 1x USB 3.2 Gen 2x2 Port (1x USB Type-C) |
| 2x USB 3.2 Gen 2 Ports (2x Type-A) | |
| 1x USB 3.2 Gen 1 Port (1x Type-A) | |
| 2x USB 2.0 Ports (2x Type-A) | |
| 1x DisplayPort | |
| 1x VGA Port | |
| 1x HDMI Port | |
| 1x Vertical M.2 Slot (Key E) | |
| 1x Realtek 2.5Gb Ethernet Port | |
| 3x Audio Jacks | |
| Internal I/O Connectors | Fan and Cooling related |
| 1x 4-pin CPU Fan header | |
| 1x 4-pin AIO Pump header | |
| 3x 4-pin Chassis Fan headers | |
| Power related | |
| 1x 24-pin Main Power connector | |
| 1x 8-pin 12V Power connector | |
| Storage related | |
| 3x M.2 slots (Key M) | |
| 4x SATA 6Gb/s ports | |
| USB | |
| 1x USB 3.2 Gen 1 connector (supports USB Type-C ) | |
| 1x USB 3.2 Gen 1 header supports 2 additional USB 3.2 Gen 1 ports | |
| 2x USB 2.0 headers support 4 additional USB 2.0 ports | |
| Miscellaneous | |
| 3x Addressable Gen 2 headers | |
| 1x Aura RGB header | |
| 1x Clear CMOS header | |
| 1x COM Port header | |
| 1x Front Panel Audio header (AAFP) | |
| 1x S/PDIF Out header | |
| 1x SPI TPM header (14-1pin) | |
| 1x 20-3 pin System Panel header with Chassis intrude function | |
| 1x Thunderbolt (USB4) header | |
| Special Features | ASUS 5X PROTECTION III |
| - DIGI VRM | |
| - LANGuard | |
| - Overvoltage Protection | |
| - SafeSlot Core | |
| - Stainless-Steel Back I/O | |
| ASUS Q-Design | |
| - Q-DIMM | |
| - Q-LED Core | |
| - Q-Slot | |
| ASUS Thermal Solution | |
| - M.2 Heatsink | |
| - VRM Heatsink Design | |
| ASUS EZ DIY | |
| - ProCool | |
| Aura Sync | |
| - Aura RGB Header | |
| - Addressable Gen 2 Headers | |
| BIOS | 128 Mb Flash ROM |
| UEFI AMI BIOS | |
| Operating System | Windows 11, Windows 10 64-bit |
| Form Factor | ATX Form Factor |
| 30.5 cm x 24.4 cm | |
| Brand | ASUS |
| Series | PRIME B760-PLUS D4 |
| Model | 90MB1CW0-M0EAY0 |
| CPU | Intel Socket LGA1700 for 13th Gen Intel Core & 12th Gen Intel Core, Pentium Gold and Celeron |
| Processors* | |
| Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0** | |
| * Refer to www.asus.com for CPU support list. | |
| ** Intel Turbo Boost Max Technology 3.0 support depends on the CPU types. | |
| Chipset | Intel B760 Chipset |
| Memory | 4 X DIMM, Max. 128GB, DDR4 5066(OC)/5000(OC)/4800(OC)/4600(OC)/4400(OC)/4266(OC)/4000(OC)/3733(OC)/3600(OC)/3466(OC)/3400(OC)/3333(OC)/3200/3000/2933/2800/2666/2400/2133 Non-ECC, Un-Buffered Memory* |
| Dual Channel Memory Architecture | |
| Supports Intel Extreme Memory Profile (XMP) | |
| OptiMem | |
| * Supported Memory Types, Data Rate (Speed), And Number Of DRAM Modules Vary Depending On The CPU And Memory Configuration, For More Information Please Refer To CPU/Memory Support List Under The Support Tab Of Product Information Site Or Visit Https://www.asus.com/support/. | |
| Graphics | 1 X DisplayPort** |
| 1 X VGA Port | |
| 1 X HDMI Port*** | |
| * Graphics Specifications May Vary Between CPU Types. Please Refer To www.intel.com For Any Updates. | |
| ** Supports Max. 4K@60Hz As Specified In DisplayPort 1.4. | |
| *** Supports 4K@60Hz As Specified In HDMI 2.1. | |
| Expansion Slots | Intel 13th & 12th Gen Processors* |
| 1x PCIe 5.0 X16 Slot | |
| Intel B760 Chipset | |
| 1x PCIe 4.0 X16 Slot (Supports X4 Mode) | |
| 2x PCIe 3.0 X1 Slots | |
| Note: To Ensure Compatibility Of The Device Installed, Please Refer To https://www.aasus.com/support/ For The List Of Supported Peripherals. | |
| Storage | Total Supports 3x M.2 Slots And 4x SATA 6Gb/S Ports* |
| Intel 13th & 12th Gen Processors | |
| M.2_1 Slot (Key M), Type 2242/2260/2280 (Supports PCIe 4.0 X4 Mode) | |
| Intel B760 Chipset | |
| M.2_2 Slot (Key M), Type 2242/2260/2280/22110 (Supports PCIe 4.0 X4 Mode) | |
| M.2_3 Slot (Key M), Type 2242/2260/2280 (Supports PCIe 4.0 X2 Mode) | |
| 4x SATA 6Gb/S Ports | |
| * Intel Rapid Storage Technology Supports SATA RAID 0/1/5/10. | |
| Ethernet | 1x Realtek 2.5Gb Ethernet |
| Wireless & Bluetooth | Vertical M.2 slot only (Key E, CNVi & PCIe)* |
| * Wi-Fi module is sold separately. | |
| USB | Rear USB (Total 6 Ports) |
| 1x USB 3.2 Gen 2x2 Port (1 X USB Type-C) | |
| 2x USB 3.2 Gen 2 Ports (2 X Type-A) | |
| 1x USB 3.2 Gen 1 Port (1 X Type-A) | |
| 2x USB 2.0 Ports (2 X Type-A) | |
| Front USB (Total 7 Ports) | |
| 1x USB 3.2 Gen 1 Connector (Supports USB Type-C) | |
| 1x USB 3.2 Gen 1 Header Supports 2 Additional USB 3.2 Gen 1 Ports | |
| 2x USB 2.0 Headers Support 4 Additional USB 2.0 Ports | |
| Audio | Realtek 7.1 Surround Sound High Definition Audio CODEC* |
| - Supports: Jack-Detection, Multi-Streaming, Front Panel Jack-Retasking | |
| - Supports Up To 24-Bit/192 KHz Playback | |
| Audio Features | - Audio Shielding |
| - Premium Audio Capacitors | |
| - Dedicated Audio PCB Layers | |
| * A Chassis With An HD Audio Module In The Front Panel Is Required To Support 7.1 Surround Sound Audio Output. | |
| Back Panel I/O Ports | 1x USB 3.2 Gen 2x2 Port (1x USB Type-C) |
| 2x USB 3.2 Gen 2 Ports (2x Type-A) | |
| 1x USB 3.2 Gen 1 Port (1x Type-A) | |
| 2x USB 2.0 Ports (2x Type-A) | |
| 1x DisplayPort | |
| 1x VGA Port | |
| 1x HDMI Port | |
| 1x Vertical M.2 Slot (Key E) | |
| 1x Realtek 2.5Gb Ethernet Port | |
| 3x Audio Jacks | |
| Internal I/O Connectors | Fan and Cooling related |
| 1x 4-pin CPU Fan header | |
| 1x 4-pin AIO Pump header | |
| 3x 4-pin Chassis Fan headers | |
| Power related | |
| 1x 24-pin Main Power connector | |
| 1x 8-pin 12V Power connector | |
| Storage related | |
| 3x M.2 slots (Key M) | |
| 4x SATA 6Gb/s ports | |
| USB | |
| 1x USB 3.2 Gen 1 connector (supports USB Type-C ) | |
| 1x USB 3.2 Gen 1 header supports 2 additional USB 3.2 Gen 1 ports | |
| 2x USB 2.0 headers support 4 additional USB 2.0 ports | |
| Miscellaneous | |
| 3x Addressable Gen 2 headers | |
| 1x Aura RGB header | |
| 1x Clear CMOS header | |
| 1x COM Port header | |
| 1x Front Panel Audio header (AAFP) | |
| 1x S/PDIF Out header | |
| 1x SPI TPM header (14-1pin) | |
| 1x 20-3 pin System Panel header with Chassis intrude function | |
| 1x Thunderbolt (USB4) header | |
| Special Features | ASUS 5X PROTECTION III |
| - DIGI VRM | |
| - LANGuard | |
| - Overvoltage Protection | |
| - SafeSlot Core | |
| - Stainless-Steel Back I/O | |
| ASUS Q-Design | |
| - Q-DIMM | |
| - Q-LED Core | |
| - Q-Slot | |
| ASUS Thermal Solution | |
| - M.2 Heatsink | |
| - VRM Heatsink Design | |
| ASUS EZ DIY | |
| - ProCool | |
| Aura Sync | |
| - Aura RGB Header | |
| - Addressable Gen 2 Headers | |
| BIOS | 128 Mb Flash ROM |
| UEFI AMI BIOS | |
| Operating System | Windows 11, Windows 10 64-bit |
| Form Factor | ATX Form Factor |
| 30.5 cm x 24.4 cm | |
| Warranty Information | |
| Warranty | 3 Year Warranty |
